Server Proxmox VE Datacenter M1A

Product Name: Server Proxmox VE Datacenter M1A

Main board: H13SSW

Chassis: 1U Rackmount with rack mounting via rails

CPU: Single 4th Generation AMD EPYC™ 9004 Series Processors

Memory: 12 DIMMs; Up to 3TB 3DS ECC RDIMM, DDR5-4800MHz in 12 DIMM slots

NIC: Supports the following connectivity:

• 1 Gbit Ethernet NIC with RJ45 connector
• 10 Gbit Ethernet NIC with RJ45 connector
• 10 Gbit SFP+ Fiber Optic NIC with LC connector
• 25 Gbit SFP28+
• 40 Gbit QSFP+
• 100 Gbit QSFP+
• Integrated IPMI 2.0 + KVM with dedicated LAN

Expansion Slots:

• 1 PCIe 5.0 x16 Right Riser Slot
• 1 PCIe 5.0 x16 Left Riser Slot
• 2 PCIe 5.0 x16 AIOM Networking Slot
• M.2 Interface: 2 PCI-E 4.0 x4
• M.2 Interface: 2 PCIe 3.0 x2
• Form Factor: 2280/22110
• Key: M-Key

Power Supply: 860W Redundant Titanium Level PER NODE

Power Consumption: 100 Watt – 750 Watt energy consumption depending on the configuration.

USB:

• 2 USB 2.0 ports (2 front)
• 2 USB 3.0 ports (2 rear)

Input/Output:

• 10x 2.5" hot-swap NVMe/SATA/SAS drive bays
• LAN: Networking provided via AIOM - 1 RJ45 Dedicated IPMI LAN port
• USB: 2 USB 3.0 ports (rear)
• COM: 1 COM Port (rear)
• Video: 1 VGA port

Front Panel:

• Power LED
• Hard drive activity LED
• Network activity LEDs
• System Information LED
• Information LED (temperature, status)

Remote Management (IPMI):

• Support for Intelligent Platform Management Interface v.2.0
• IPMI 2.0 with virtual support over LAN and KVM support over LAN, KVM with HTML 5

Operating Temperature: Operates between 10~35 degrees Celsius

Dimensions: 597 mm x 437 mm x 43 mm (DxWxH) (1U rackmount)

Available Colors: Black (as shown in product image)
