Server Proxmox VE Tower T3
Tower Server tested and certified for Proxmox VE, designed for companies that need power, flexibility and reliability.
- It offers high performance provided by 2 Intel Xeon CPUs, up to 8 disks,
- 3.5” Hot-Swapp SAS/SATA or 4 NVMe, Enterprise Server class,
- Equipped by default with dual 10 Gbit copper connectivity on board,
- Titanium Level redundant power supply and dedicated IPMI port for remote management of the Server.
The configuration options allow the installation of 1, 10, 25, 40 and 100 Gbit copper or fiber connectivity.
The package includes: the server, n. 1 power cable.
Availability:
In stock
SKU
ST3SUC2S8P2TG2_24
Product Name Server Proxmox Tower T3
Main board Supermicro X13DEI-T
Chassis Tower
CPU Dual Socket E (LGA-4677) 5th/4th Gen Intel® Xeon® Scalable processors, supports up to 300W TDP
Memory 16 DIMM slots, Up to 4TB DDR5-5600MHZ/4800MHz ECC Registered RDIMM
NIC Onboard: 2 Dual Gigabit LAN ports
Optional:
up to 8 NIC 1 Gbit Copper RJ45 connector
up to 8 NIC 10 Gbit Copper RJ45 connector
up to 8 NIC 10 Gbit SFP+ Fiber Optic LC connector
up to 8 NIC 1 Gbit SFP Fiber Optic LC connector
up to 6 NIC 25 Gbit QSFP+
up to 6 NIC 40 Gbit QSFP+ up to 6 NIC 100 Gbit QSFP28 Expansion Slots PCI-Express: 2 PCIe 5.0 x8 FHFL slot(s) 4 PCIe 5.0 x16 FHFL slot(s) Drive Bays: Default: Total 8 bay(s) 4 front hot-swap 3.5" NVMe*/SAS*/SATA drive bay (s) 4 front hot-swap 3.5" SAS*/SATA drive bay(s) Option A: Total 8 bay(s) 4 front hot-swap 2.5" NVMe*/SAS*/SATA drive bay(s) 4 front hot-swap 2.5" SAS*/SATA drive bay(s) Power 1200W (1 + 1) Redundant Titanium Level Certified High-Efficiency
Power Supply
Power Consumption 180 Watts – 650 Watts of power consumption depending on configuration.
USB 2 USB 3.0 port(s) (front) 4 USB 3.0 port(s) (rear) Input/Output LAN
1 RJ45 1 GbE Dedicated BMC LAN port(s) USB
2 USB 3.0 port(s) (front)
4 USB 3.0 port(s) (rear) Video
1 VGA port(s)
1 COM port(s) (Rear) DOM
2 SuperDOM (Disk on Module) port(s)
TPM 1 TPM Onboard/port 80
Front Panel Buttons: Power On/Off button - System Reset button LEDs: Power status LED - HDD activity LED - Network activity LEDs - System information (overheat/UID) LED
Remote Management (IPMI) . Support for Intelligent Platform Management Interface v.2.0;
. IPMI 2.0 with virtual support over LAN and KVM support over LAN, KVM with HTML 5.
Temperature Operates between 10~35 degrees centigrade
Dimensions Tower: (WxHxL) 76 x 40 x 336 mm
Available Colors Black (as per product photo)
